| Parameter | Value | Remarks |
| AC input： | ||
| Rated input voltage | 380Vac | Three phase AC，Customizable |
| Input voltage range | 285~475Vac | Three phase AC，Customizable |
| Frequency range | 47-63 Hz | / |
| Input current | ≤45A Max | Sum of three-phase current |
| Efficiency | ≥90% | Under rated condition |
| power factor | ≥0.98 | Under rated condition |
| DC output：3KW | ||
| Output voltage range | 18-60V | Dynamically adjustable，Customizable |
| Output current range | 0~150A | Dynamically adjustable，Customizable |
| Maximum output power | 9000W | |
| Current accuracy | ±5% | / |
| Voltage accuracy | ±5% | / |
| Ripple voltage | ≤±1%Vo | 20MHz |
| Design life | 50000H | 25℃ |
| Communication and control： | ||
| Communication mode | CAN/RS485/TCP/WIFI | Customizable |
| Communication protocol | KH dispatching dedicated charging pile communication protocol | Customizable |
| Mechanics | ||
| Size | L415*W315*H630 mm | Standard box，Customizable |
| Weight | <50Kg | Customizable |
