| MCF AJW-A24-210Y-03 | |||
| NO. | ITEM | PARAMETERS | NOTES |
| 1 | Rated capacity | 210Ah | |
| 2 | Minimal capacity | 200Ah | |
| 3 | Rated voltage | 25.6Vdc | |
| 4 | Max.charge voltage | 29.2Vdc | |
| 5 | Discharge end voltage | 20Vdc | |
| 6 | Fast charging current | 100A | Max.charging current 150A |
| 7 | Max.constant discharging current | 200A | Max.300A sustains 15s |
| 8 | Overall dimensions | 595*173*521mm | Support customization |
| 9 | Weight | 75±5kg | Support customization |
| 10 | Power interface | REMA 160A | Support customization |
| 11 | Working temperature | -20～+45℃ | Environmental temperature |
| 12 | Charging temperature | 0~45℃ | Environmental temperature |
| 13 | Storage Temp.（Hum:45%~75%,Atm pressure:70 kPa~106kPa） | -20~ +45℃ | Environmental temperature |
| MCF AJW-A80-420Y-01 | |||
| NO. | ITEM | PARAMETERS | NOTES |
| 1 | Rated capacity | 100Ah | |
| 2 | Minimal capacity | 95Ah | |
| 3 | Rated voltage | 25.6Vdc | |
| 4 | Max.charge voltage | 29.2Vdc | |
| 5 | Discharge end voltage | 20Vdc | |
| 6 | Fast charging current | 80A | Max.charging current 100A |
| 7 | Max.constant discharging current | 100A | Max.150A sustains 15s |
| 8 | Overall dimensions | 600*90*350mm | Support customization |
| 9 | Weight | 25±5kg | Support customization |
| 10 | Power interface | SB120 | Support customization |
| 11 | Working temperature | -20～+45℃ | Environmental temperature |
| 12 | Charging temperature | 0~45℃ | Environmental temperature |
| 13 | Storage Temp.（Hum:45%~75%,Atm pressure:70 kPa~106kPa） | -20~ +45℃ | Environmental temperature |
| MCF JS-A24-210Y-06 | |||
| NO. | ITEM | PARAMETERS | NOTES |
| 1 | Rated capacity | 210Ah | |
| 2 | Minimal capacity | 200Ah | |
| 3 | Rated voltage | 25.6Vdc | |
| 4 | Max.charge voltage | 29.2Vdc | |
| 5 | Discharge end voltage | 20Vdc | |
| 6 | Fast charging current | 100A | Max.charging current 150A |
| 7 | Max.constant discharging current | 200A | Max.300A sustains 15s |
| 8 | Overall dimensions | 660*199*450mm | Support customization |
| 9 | Weight | 75±5kg | Support customization |
| 10 | Power interface | SB175 | Support customization |
| 11 | Working temperature | -20～+45℃ | Environmental temperature |
| 12 | Charging temperature | 0~45℃ | Environmental temperature |
| 13 | Storage Temp.（Hum:45%~75%,Atm pressure:70 kPa~106kPa） | -20~ +45℃ | Environmental temperature |
| MCF MNLM-V24-270M-07 | |||
| NO. | ITEM | PARAMETERS | NOTES |
| 1 | Rated capacity | 270Ah | |
| 2 | Minimal capacity | 250Ah | |
| 3 | Rated voltage | 25.6Vdc | |
| 4 | Max.charge voltage | 29.2Vdc | |
| 5 | Discharge end voltage | 20Vdc | |
| 6 | Fast charging current | 100A | Max.charging current 150A |
| 7 | Max.constant discharging current | 200A | Max.300A sustains 15s |
| 8 | Overall dimensions | 786*210*630mm | Support customization |
| 9 | Weight | 240±10kg | Support customization |
| 10 | Power interface | SB175 | Support customization |
| 11 | Working temperature | -20～+45℃ | Environmental temperature |
| 12 | Charging temperature | 0~45℃ | Environmental temperature |
| 13 | Storage Temp.（Hum:45%~75%,Atm pressure:70 kPa~106kPa） | -20~ +45℃ | Environmental temperature |
| MCF MW-V24-200M-05 | |||
| NO. | ITEM | PARAMETERS | NOTES |
| 1 | Rated capacity | 200Ah | |
| 2 | Minimal capacity | 190Ah | |
| 3 | Rated voltage | 25.6Vdc | |
| 4 | Max.charge voltage | 29.2Vdc | |
| 5 | Discharge end voltage | 20Vdc | |
| 6 | Fast charging current | 100A | Max.charging current 150A |
| 7 | Max.constant discharging current | 200A | Max.300A sustains 15s |
| 8 | Overall dimensions | 620*280*625mm | Support customization |
| 9 | Weight | 135±10kg | Support customization |
| 10 | Power interface | REMA 160A | Support customization |
| 11 | Working temperature | -20～+45℃ | Environmental temperature |
| 12 | Charging temperature | 0~45℃ | Environmental temperature |
| 13 | Storage Temp.（Hum:45%~75%,Atm pressure:70 kPa~106kPa） | -20~ +45℃ | Environmental temperature |
| MCF MW-V24-200M-05 | |||
| NO. | ITEM | PARAMETERS | NOTES |
| 1 | Rated capacity | 200Ah | |
| 2 | Minimal capacity | 190Ah | |
| 3 | Rated voltage | 25.6Vdc | |
| 4 | Max.charge voltage | 29.2Vdc | |
| 5 | Discharge end voltage | 20Vdc | |
| 6 | Fast charging current | 100A | Max.charging current 150A |
| 7 | Max.constant discharging current | 200A | Max.300A sustains 15s |
| 8 | Overall dimensions | 593*172*452mm | Support customization |
| 9 | Weight | 80±5kg | Support customization |
| 10 | Power interface | REMA 160A | Support customization |
| 11 | Working temperature | -20～+45℃ | Environmental temperature |
| 12 | Charging temperature | 0~45℃ | Environmental temperature |
| 13 | Storage Temp.（Hum:45%~75%,Atm pressure:70 kPa~106kPa） | -20~ +45℃ | Environmental temperature |
| MCF MW-V24-200Y-16 | |||
| NO. | ITEM | PARAMETERS | NOTES |
| 1 | Rated capacity | 200Ah | |
| 2 | Minimal capacity | 190Ah | |
| 3 | Rated voltage | 25.6Vdc | |
| 4 | Max.charge voltage | 29.2Vdc | |
| 5 | Discharge end voltage | 20Vdc | |
| 6 | Fast charging current | 100A | Max.charging current 150A |
| 7 | Max.constant discharging current | 200A | Max.300A sustains 15s |
| 8 | Overall dimensions | 665*199*350mm | Support customization |
| 9 | Weight | 80±5kg | Support customization |
| 10 | Power interface | REMA 160A | Support customization |
| 11 | Working temperature | -20～+45℃ | Environmental temperature |
| 12 | Charging temperature | 0~45℃ | Environmental temperature |
| 13 | Storage Temp.（Hum:45%~75%,Atm pressure:70 kPa~106kPa） | -20~ +45℃ | Environmental temperature |
